Unlike normal low-cost computer speakers, Zetron’s speakers are specifically designed for mission critical applications where reliability, ease of use, and voice fidelity are important.
Premium grade components are housed in an attractive yet rugged enclosure to optimize the reproduction of two-way radio voice-band communication. An individual volume control eliminates the confusion caused by the stereo balance control found on standard multimedia computer speakers. A high visibility call indication LED on the speaker instantly identifies the source of audio.

Zetron Microphone

Asphalt 8 mod apk for windows 10. Whichever option you choose you can be confident that the Zetron Communications microphone has been designed for mission-critical radio communications. Unlike public address or paging microphones this mike has been designed from the ground up for dispatch center use. The stable base with highly reliable switches is matched with your choice of gooseneck and capsule combination.

Speaker Features and Configuration

• Machined aluminium enclosure for stable desktop use
• High quality driver allows clear full 5-watt output at maximum volume
• Resonant cavity is tuned for optimum response at voice frequencies
• Balanced transformer input accepts line-level audio and eliminates troublesome ground loops.
• Large smooth-action volume knob for predictable adjustments
• LED confirms speaker is powered ready for use
• LED Call Indicator is triggered by the presence of an audio signal
• LED Call Indicator is not affected by the position of the volume control
• LED Call Indicator permits users to visually identify the source of incoming calls in multi-speaker (Select/Unselect) systems
• Operator cannot reduce volume below a technician-adjustable preset minimum volume level to prevent missed calls
• Operates from 12 volts DC to allow elimination of clumsy “wall bugs” in system installations

Microphone Features and Configuration

Available with a either a generic capsule on a standard-duty gooseneck or a Shure noise cancelling capsule on a heavy-duty extended length gooseneck.

MICROPHONE BASE

• Machined aluminium base enclosure for stability
• Red Double-wide TRANSMIT pushbutton,
• White MONITOR pushbutton
• Long life switches rated for 50 million cycles
• Always-live microphone output allows for parallel PTT footswitch
• Isolated and balanced output (Mic+ and Mic-)

GENERIC GOOSENECK MICROPHONE

• Cardioid pickup pattern
• Dynamic microphone cartridge
• Frequency response: 100 to 12 kHz
• Sensitivity: -52 dBV / Pa
• Impedance: 600 ohm
• 8.5” gooseneck

SHURE GOOSENECK MICROPHONE

• Shure 503BG Cardioid dynamic noise canceling capsule
• Smooth frequency response with excellent fidelity in the voice range
• Close-talking operation keeps unwanted signals and background noise at low levels
• Constant output over voice spectrum when close talked
• Humbucking coil minimizes undesirable hum effects such as CRT interference
• Low-impedance (170 ohm) design permits long cable runs in extreme hum fields
• Frequency response: tailored to communications use (100 Hz to 7 kHz)
• Sensitivity: -61.5 dBV / Pa
• Longer 12.5 inch gooseneck for optimal positioning

The Model 4010 (Desktop) and Model 4010R (Rackmount) Radio Consoles are self-contained, single position radio console systems which accommodates up to 12 radio channels and 2 telephone lines. The units are compact and versatile. Camtasia dmg.

The Model 4010’s modular design and programmability allow the unit to be configured to meet a wide range of public safety, government, institutional and industrial applications.

The Model 4010 is rigidly constructed, and is rated for continuous 7 day/24 hour applications with a proven track record of field reliability under the most demanding conditions. It is also suitable for portable applications, such as temporary or mobile Control Centers.

Zetron 4010 Programming Manual Instructions

The Model 4010 has programmable function buttons for functions such as group call, channel select, channel mute, and channel patch. There is an integral keypad and LCD to display incoming calls. Two separate speakers are provided to allow the operator to hear selected and monitored audio, with volume levels adjusted on each individual channel. The operator options include a handset, gooseneck or desk microphone, headset and footswitch. Base station control is local or remote, using tone remote control 2970 Hz keytone, DC or E.

Zetron Inc

Model 4010 Standard Product Features and Configuration

• Expandable rackmount or office-styled desktop configuration
• Flexible paging encoder
• Supports DTMF, Motorola/GE Two-Tone, Plectron, 5/6 Tone, Quick Call I (2+2), Knox, and Rotary Dial
• Accommodates most industry standard radio interfaces including: Tone Remote, DC Remote, Local Control and E
• Supports one or two telephone lines with intuitive controls: 'answer', 'release', and 'hold'
